Sharkmouth

122mm Gun as used on the IS series

The bright close up photos are from the ex-Aberdeen Proving Grounds example now at the Military Museum of Southern New England in Danbury, CT. Yes, near the AMPS East show!



The olive green colored photos are from two vehicles in Warsaw, Poland taken during 2002.
